Undo step which modifies object tags. More...
#include <object_undo.h>
Public Member Functions | |
| ObjectTagsUndoStep (Map *map) | |
| ~ObjectTagsUndoStep () override | |
| void | addObject (int index) override |
| Adds an object (by index) to this step. More... | |
| UndoStep * | undo () override |
| Undoes the action and returns a new UndoStep. More... | |
 Public Member Functions inherited from OpenOrienteering::ObjectModifyingUndoStep | |
| ObjectModifyingUndoStep (Type type, Map *map) | |
| Creates an ObjectModifyingUndoStep for the given map and its current part. More... | |
| ObjectModifyingUndoStep (Type type, Map *map, int part_index) | |
| Creates an ObjectModifyingUndoStep for the given map and part. More... | |
| ~ObjectModifyingUndoStep () override | |
| Destructor. More... | |
| int | getPartIndex () const |
| Returns the index of the map part modified by this undo step. More... | |
| void | setPartIndex (int part_index) |
| Set the index of the map part modified by this undo step. More... | |
| virtual bool | isEmpty () const |
| Returns true if no objects are modified by this undo step. More... | |
| bool | getModifiedParts (PartSet &out) const override |
| Adds the the step's modified part to the container provided by out. More... | |
| void | getModifiedObjects (int part_index, ObjectSet &out) const override |
| Adds the list of the step's modified objects to the container provided by out. More... | |
| Public Member Functions inherited from OpenOrienteering::UndoStep | |
| UndoStep (Type type, Map *map) | |
| Constructs an undo step having the given type. More... | |
| UndoStep (const UndoStep &)=delete | |
| UndoStep (UndoStep &&)=delete | |
| virtual | ~UndoStep () |
| Destructor. More... | |
| UndoStep & | operator= (const UndoStep &)=delete |
| UndoStep & | operator= (UndoStep &&)=delete |
| Type | getType () const |
| Returns the type of the undo step. More... | |
| virtual bool | isValid () const |
| Returns true if the step can still be undone. More... | |
| void | save (QXmlStreamWriter &xml) const |
| Saves the undo step to the stream in xml format. More... | |
Protected Types | |
| typedef std::map< int, Object::Tags > | ObjectTagsMap |
| Protected Types inherited from OpenOrienteering::ObjectModifyingUndoStep | |
| typedef std::vector< int > | ObjectList |
| A list of indices referring to objects in a map part. More... | |
Protected Member Functions | |
| void | saveObject (XmlElementWriter &xml, int index) const override |
| Saves object details to the the xml stream. More... | |
| void | loadObject (XmlElementReader &xml, int index) override |
| Loads object details from the the xml stream. More... | |
| Protected Member Functions inherited from OpenOrienteering::ObjectModifyingUndoStep | |
| void | saveImpl (QXmlStreamWriter &xml) const override |
| Saves undo properties to the the xml stream. More... | |
| void | loadImpl (QXmlStreamReader &xml, SymbolDictionary &symbol_dict) override |
| Loads undo properties from the the xml stream. More... | |
Protected Attributes | |
| ObjectTagsMap | object_tags_map |
| Protected Attributes inherited from OpenOrienteering::ObjectModifyingUndoStep | |
| ObjectList | modified_objects |
| Indices of the existing objects that are modified by this step. More... | |
| Protected Attributes inherited from OpenOrienteering::UndoStep | |
| Type const | type |
| The type of the undo step. More... | |
| Map *const | map |
| The map this undo step belongs. More... | |
Additional Inherited Members | |
| Public Types inherited from OpenOrienteering::UndoStep | |
| enum | Type { ReplaceObjectsUndoStepType = 0, DeleteObjectsUndoStepType = 1, AddObjectsUndoStepType = 2, SwitchSymbolUndoStepType = 3, SwitchDashesUndoStepType = 4, CombinedUndoStepType = 5, ValidNoOpUndoStepType = 6, ObjectTagsUndoStepType = 7, MapPartUndoStepType = 8, SwitchPartUndoStepTypeV0 = 9, SwitchPartUndoStepType = 10, InvalidUndoStepType = 999 } |
| Types of undo steps for identification. More... | |
| typedef std::set< int > | PartSet |
| A set of integers referring to parts. More... | |
| typedef std::set< Object * > | ObjectSet |
| A set of pointers to objects. More... | |
| Static Public Member Functions inherited from OpenOrienteering::UndoStep | |
| static UndoStep * | getUndoStepForType (Type type, Map *map) |
| Constructs an undo step of the given type. More... | |
| static UndoStep * | load (QXmlStreamReader &xml, Map *map, SymbolDictionary &symbol_dict) |
| Loads the undo step from the stream in xml format. More... | |
Undo step which modifies object tags.
|
protected |
| OpenOrienteering::ObjectTagsUndoStep::ObjectTagsUndoStep | ( | Map * | map | ) |
|
override |
|
overridevirtual |
Adds an object (by index) to this step.
The object must belong to the step's part.
Reimplemented from OpenOrienteering::ObjectModifyingUndoStep.
|
overrideprotectedvirtual |
Loads object details from the the xml stream.
The default implemenentation does nothing.
Reimplemented from OpenOrienteering::ObjectModifyingUndoStep.
|
overrideprotectedvirtual |
Saves object details to the the xml stream.
The default implemenentation does nothing.
Reimplemented from OpenOrienteering::ObjectModifyingUndoStep.
|
overridevirtual |
Undoes the action and returns a new UndoStep.
The returned UndoStep can redo the action again.
Implements OpenOrienteering::UndoStep.
|
protected |
